H02 Isolated RS485 HUB 1:3 3kV DC Isolation Side (3)
H02 Isolated RS485 HUB 1:3 3kV DC Isolation Side (3)
- Isolated RS485 1:3 HUB Branched Side (3) Isolated 3kV DC Isolation
Product description
Redisage's H02 is a reliable RS485 signal HUB made to work with variable transmission speeds up to 115200 bps. It allows flexible branching of the 1:3 interface while simultaneously protecting the attached devices with a 3 kVDC branched side isolation. Additionally, a dedicated EMC protection circuit improves transmission quality in an industrial environment. H02 is powered with 12-30 VDC or 24 VAC and ensures low power consumption of less than 1W.
Technical Documentation
| Operations and Maintenance Manual | H02 Datasheet and Selection Guide |  |
| Redisage Documentation Space | doc.redisage.com |
Main data
Power voltage
12-30 V/DC
Galvanic isolation
Slave RS485 3 kV/DC
Power connector
Screw terminal
Work temperature range
-40°C to +75°C
Safety measures
ESD 4 kV / 8 kV
Burst
Surge
RF
LED
Tx
4x Rx
Power
Serial Ports
Number of ports
4
Port type
4x RS485
Connector type
Screw terminal
Transmission speed
115200 bps
Data bits
7
8
Stop bits
1
2
Controll Bits
none
odd
even
Enclosure
Ingress Protection Code
IP20
Length
98 mm
Height
56.4 mm
Width
22.5 mm
Width in standard modules S (17.5 mm)
1.5 Module
Mounting
DIN Rail
Standards and Certifications
Declarations of Conformity
CE
RoHS
EMC
LVD
Norms
61000-6-2 - Immunity standard for industrial environments
61000-6-4 - Emission standard for industrial environments
3 Year Warranty
